Description

:

Z Master® 5000 Series – 25 hp (18.4kW) Kohler® Command Pro EFI 747cc Engine with 60 in. (152 cm) TURBO FORCE® deck.

Features:

• Deluxe suspension seat features thick cushions, large bolsters and 3-D isolator mounts that absorb bumps and vibrations to reduce operator fatigue, fully adjustable to match operator comfort
• Our TURBO FORCE deck features heat-treated steel blades and our patented adjustable discharge chute, nothing cuts as fast or as well
• Unitized pump and wheel motor uses proven commercial hydraulic components while eliminating hoses and other potential leak points
• Horizon360® Business Management Software. Work More Efficiently. Run More Profitably.

Specifications:

• Adjustable Discharge Baffle: Standard, Tools-Free
• Air Filter: Heavy-Duty Canister Air Cleaner
• Anti Scalp Wheels: 4 Standard, 1 Optional
• Armrests: Standard
• Blade Tip Speed: 18,500 ft/min / 5,638 m/min
• Blades: 0.204 in. (0.5 cm) heat-treated steel
• Box Dimensions: 91 in. x 70.5 in. x 52.5 in. / 213.1 cm x 179.1 cm x 133.4 cm
• CARB Compliant: Not CARB Compliant
• Carrier Frame: 3 in. x 1.5 in. x 10 gauge (7.6 cm x 3.8 cm x 10 gauge)
• Caster Tires: 13 in. x 6.5 in. – 6 in. (33 cm x 16.5 cm – 15.2 cm) Flat-Free Semi-Pneumatic
• Comfort Platform: Deluxe Suspension with 3-D Isolation Mounts
• Deck Design: 80-Grade 7-gauge 60″ (152 cm) TURBO FORCE® w/bull-nose bumper
• Deck Material: 9 Gauge Steel
• Deck Size: 60 in / 152 cm
• Discharge Chute: Rubber
• Drive System: Hydraulic Unitized Pumps and Wheel Motors
• Drive Tires: 24 in. x 12 in. – 12 in. (61 cm x 30.5 cm – 30.5 cm)
• Engine: 25 hp* (18.4kW) Kohler® Command Pro EFI 747 cc
• Engine Brand: Kohler
• Engine Displacement (cc): 747 cc
• Engine Horsepower: 25 hp
• Forward Ground/Transport Speed: Up to 10.0 mph / 16.0 kph
• Front Bumper: Reinforced Bull-Nose
• Fuel Capacity: 12 gal. / 45.4 L / 48 Qt.
• Fuel Type: Gasoline
• Height of Cut: 1.0 – 5.5 in. / 2.5 – 14.0 cm
• Hour Meter: Standard
• Hydraulic Fluid: Premium synthetic
• Product Type: Zero Turn Mowers
• Product Use: Commercial
• Roll-Over Protection (ROPS): Folding; Standard
• Seat: Handcrafted Deluxe Suspension Seat with Arm Rests Featuring Bullhorn Accent
• Spindle Bearings: Maintenance-free
• Spindle Housing: 9 in / 22.9 cm Diameter Cast Aluminum
• Start Type: Electric
• Steering Controls: 1-5/8″ (4.1 cm) Diameter Grips; Adjustable, Dampened
• Weight: 1,240 lbs / 562.5 kg
