Description

********NO LONGER AVAILABLE********

 SET UP AND PREP FEES MAY APPLY

• A strong 18 HP Kawasaki® engine delivers reliable power to tackle your yard.
• 42-in. heavy-duty fabricated AeroForce™ deck cutting system delivers a best-in-class cut with fewer clumps, finer clippings and increased evenness
• AGM battery delivers reliable starting with slower discharge so you worry less about your battery going dead in the offseason.
• Tuff Torq Hydrostatic transmission, no shifting, just push the pedal and go.

Engine

• Engine:  Kawasaki FR600V-FS06 18HP
• Engine Displacement:603cc
• Fuel Tank Capacity:3.0 gal.
• Cylinders/Material: Twin Cast Iron
• Engine Start: Key
• Engine Oil Capacity:1.8 qts.
• Lubrication:  Fully pressurized
• Battery:  12V 300 cold crank amps
• Charging System:  15 Amp Regulated
• Fuel Gauge:  Fuel sight window
• Governor:  Manual
• Choke:  Separate Choke and Throttle
• Air Filter:  Dual element
• Oil Filter:  Yes
•

Drive System

• Transmission:  Hydrostatic, foot
• Forward Speed:  5.5 MPH
• Reverse Speed:  3.1 MPH
• Rear Axle:  3/4″ w/dual PM steel drive hubs
• Transmission Housing:  Cast aluminum
• Transmission Type:  Tuff Torq K46
•

Cutting Deck

• Deck Cutting Width:  42″
• Cutting Modes:  Discharge/mulch/bagging
• Deck Wash:  Included
• Deck Attach/Removal:  QuickAttach™ (no tools required)
• Deck Engagement (PTO):  Manual lever
• Blade(s):  2
• Deck Lift:  Lever/spring assisted
• Cutting Height Range:  1″ – 4″
• Anti-Scalping:  2 ball
• Deck Positions: 12 positions
•

Chassis

• Frame:  Robotically welded
• Front Axle(s):  Heavy duty Cast iron
• Turning Radius:  16″
• Front Tires:  15″x6″-6″
• Rear Tires:  20″x8″-8″
• Tire Tread:  Multi-Trac
• Rear Tow Hitch:  Included
• Corrosion Protection:  E-coating
•

Controls

• Cruise Control:Soft touch engagement
• Brakes:  Automotive-style disc
• Direction:NEW optimized steering system, manual sector and pinion
• Headlight(s):  2 – LED High Illumination
• Display Hour meter
•

Comfort

• Seat Type:Cub Comfort™ high-back seat
• Arm Rests:  Comfort
• Seat Suspension:  Seat spring
• Seat Adjustment:  Lever
• Floor Mats:  Traction Pad
• Seat adj: 10 degree incline and slide
•

Additional Specifications

• Mulch Kit:  Optional
• Discharge Chute:  Included
• Cup Holder:  Included
• Operator Presence System:  Included
• Bagger:  Optional
•

Warranty

• Warranty:  3-year/unlimited hour warranty
• Frame Warranty:  5-year/unlimited hour warranty
• Front Axle Warranty:  5-year/unlimited hour warranty

• AIR FILTER:  KM-11013-0727
• OIL FILTER:  KM-49065-0721
• FUEL FILTER:KM-49019-0031
• SPARK PLUG:  KM-BPR4ES
• DECK BELT:  954-05021
• DRIVE BELT:  954-05027B
• BLADES ORDER 2:742P05177
• XTREME BLADES: 742P05177A-X
• IGNITION KEY:  925-1745A
